The hardware of the ToF sensor can be divided into a transmitting end and a receiving end. The transmitting end is composed of a VCSEL laser source, a collimating lens and a DOE diffuser, and the receiving end is composed of a narrowband filter, an optical lens and an infrared CIS.
Tof sensor is an important component to realize AR and VR, making the performance of VR equipment more advanced. DOMI tof sensor is suitable for AR and VR applications, welcome to consult.
In recent years, Emergence of cost-effective 3D depth cameras has greatly accelerated the development of robotics and 3D vision. This article introduces a list of some common 3D depth cameras. so that users can easily obtain information about DOMI 3D depth camera.
Current DOMI tof camera have been applied to the field of face recognition. The highest resolution of DOMI tof camera products can reach VGA (640x480) 300k, and the frame rate can support up to 60 FPS.
Comparing the principles and systems of 3D structured light and Tof sensor, the performance and application scenarios of the two solutions can be further analyzed.
Full name of TOF is Time of Flight.After the light of the modulated light source of the camera is emitted, it is reflected back by the object, and there will be a time difference. According to this time difference, through a specific algorithm, the distance of the object from the camera can be estimated.
As manufacturer of tof sensors, DOMI uses a combination of ToF Camera to create a more efficient robot vision system. The ToF Camera rovides sensor chips and supporting interface chips, which can realize reliable 3D imaging solutions,
Each pixel inside the ToF camera can get a corresponding distance, and the distance measured by all the pixels constitutes a depth map, as shown in the figure below. The left is the original image, and the right is the corresponding depth image.
ToF camera uses active light detection, which usually includes the following parts:
DM_RGBD_5002A ToF camera is based on a new generation of CW pixel design, with a fine resolution of 640×480 and a precision level of 0.5%. DM_RGBD_5002A ToF camera will be used in high-precision, high-definition 3D applications such as smartphones
